SRS80 Series
Bore mounting Slip Ring Assemblies
Specification | |
Size | OD : 80 / L1 : 59.5 / L2 : 71 |
No. of Ch. | 16 |
Voltage | 28 VDC |
Current | 5 A |
Rotating speed | 15 RPM |
Mounting | End mountiing |
Application | Construction equipment, Wind energy, FA etc. |
advantage | IP65, no lubrication required |
[Dimensions]
Part Number | Length "L" | |
"L1" | "L2" | |
SRB80-16 | 67 | 82 |
